Description
Features
Convenient Features
A square cook plate on the top of the stove is great for warming things up. It also provides easy access to the catalyst for servicing.
Soapstone Comfort
Full soapstone + cast iron construction offers comfortable, long-lasting heat and a lifetime of trouble free service.
TruHybrid™ System
Technology so advanced, you can get up to a 30% tax credit (IRS 25C) for the entire installation!
Specifications
BTU: Up to 23,000
Efficiency: 78.5%
EPA Certified: 1.14 g/hr
Finish: Matte Black
Firebox Capacity: 1.0 cubic feet
Flue Exit Diameter: 6″
Flue Exit Location: Top
HeatLife: 9.5
Heats up to: 575 sq. ft.
Maximum Log Length: 18″ (16″ recommended)
Model: 8060
Stove Type: Soapstone Wood Stove
Weight: 195 lbs.
Accessories
Rear Heat Shield: 90-68601
Side Heat Shield: 90-68605
Outside Air Stater Kit, 3″: 96-53400
Outside Air Increaser, 3″ to 4″: 90-53308
Clearances
Side: 22″
Rear: 9″
Corner: 13.75″
Double-wall connector pipe, no heat shields
Side: 9″
Rear: 3.5″
Corner: 7.25″
Double-wall connector pipe with side & rear heat shields
